Intel NUC i3-1220P 4.40GHz 2xDDR4 SODIMM M.2 SSD Iris Xe Graphics 4xDisplays 2xHDMI 2xDP via USB-C 2xTB4 2.5GbE 4xUSB WiFi6E

Essentials
Product Collection Intel® NUC Kit with 12th Generation Intel® Core™ Processors
Code Name Products formerly Wall Street Canyon
Supported Operating Systems Windows 11 Home* | Windows 11 Pro* | Windows 10 Home* | Windows 10 IoT Enterprise* | Windows 10 Pro* | Red Hat Linux* | Ubuntu 20.04 LTS*
Board Form Factor UCFF (4″ x 4″)
Socket Soldered-down BGA
Internal Drive Form Factor M.2 SSD
# of Internal Drives Supported 2
TDP 20 W
Lithography Intel 7
Max Turbo Frequency 4.40 GHz
Embedded Options Available No
Max Memory Size (dependent on memory type) 64 GB
Memory Types DDR4-3200 1.2V SODIMMs
Max # of Memory Channels 2
Max # of DIMMs 2
ECC Memory Supported ‡ No
Integrated Graphics ‡ Yes
Graphics Output 2x HDMI 2.1 TMDS Compatible | 2x DP 1.4a via Type C
# of Displays Supported ‡ 4
PCI Express Revision Gen 4 (m.2 22×80 slot); Gen 3 (otherwise)
PCI Express Configurations ‡ PCIe x4 Gen 4: M.2 22×80 (key M) PCIe x1 Gen 3: M.2 22×42 (key B) PCIe x1: M.2 22×30 (key E)
M.2 Card Slot (wireless) 22×30 (E)
M.2 Card Slot (storage) 22×80 NVMe (M); 22×42 SATA (B)
# of USB Ports 4i225-V
Integrated Wireless‡ Intel® Wi-Fi 6E AX211(Gig+)
Integrated Bluetooth Yes
